P5

•	Resolution	:	32(H) x 64(W)
•	Pitch	:	5mm
•	Density	:	40.000 pixels
•	LED Arrangement	:	SMD3528
•	Driver Mode	:	16s
•	Size	:	320mm x 160mm
•	Mask	:	Pure Black mask-high contrast screen
•	Brightness	:	1800cd
•	View Angle	:	140 degree ( horizontal) 140degree(vertical)
•	View Distance	:	4m - 240m
•	Gray Scale	:	8bits input, correction with 16bits
•	Display Color	:	16.7M
•	Brightness Adjustment	:	100 levels
•	Operation Power	:	AC100-240V 50-60HZ Switch-able
•	Maxim Power Consumption	:	1000 w
•	Average Power Consumption	:	440 w
•	Correction Scale Level	:	16bits
•	Frame Update Frequency	:	60Hz
•	Screen Refresh Frequency	:	2880Hz
•	Gamma Correction	:	-5.0mdash5.0
•	Support Input	:	Composite Video, S-Video, DVI, HDMI., SDI
•	Control Distance	:	Ethernet cable 100m, optical fiber 5km
•	Support VGA Mode	:	1024x768,1920 x1080
•	Color Temperature	:	5000-9300 adjustable
•	Brightness Correction	:	dot by dot, module by module,cabinet by cabinet
•	Operating Temp	:	-20?- +60?
•	Operating Humidity	:	10-95% RH
•	Operating Life	:	100,000 hours
•	MTBF	:	5000 hours
•	Continuous Working Time	:	72hours
•	Protection Level	:	IP25
•	Out of Control Pixel Rate	:	0.01%
